Cellular Geocell

Name: China Cellular Geocell Manufacturers, Suppliers and Factory - Low Price Cellular Geocell - Ruiheng Building Materials
Brand: Ruiheng
SKU: 270435711

Cellular Geocell is a revolutionary geosynthetic material designed for superior soil stabilization, erosion control, and load support in various civil engineering and construction applications. Made from high-strength, durable polymers, Cellular Geocell provides a three-dimensional honeycomb structure that confines and reinforces infill materials, significantly enhancing ground stability and longevity.
Whether used in road construction, slope protection, retaining walls, or landscaping, Cellular Geocell delivers unmatched performance by distributing loads evenly, reducing material costs, and minimizing environmental impact. Its flexible yet robust design ensures long-term durability even in the harshest conditions.

Send Inquiry

Description

Cellular Geocell Products Description

product-810-408

Item Model	Height (mm)	Welding distance (mm)	Sheet thickness (mm)		Seam peel strength ≥(N)	Expanded Cell Size (mm)	Expanded Panel Size (m)
Item Model	Height (mm)	Welding distance (mm)	smooth	texture	Seam peel strength ≥(N)	Expanded Cell Size (mm)	Expanded Panel Size (m)
CELL-100-330	100	330	1.1	1.5	1420	244*203	2.44*6.15
CELL-150-330	150				2130	244*203	2.44*6.15
CELL-200-330	200				2840	244*203	2.44*6.15
CELL-100-356	100	356	1.1	1.5	1420	259*224	2.56*6.52
CELL-150-356	150				2130	259*224	2.56*6.52
CELL-200-356	200				2840	259*224	2.56*6.52
CELL-100-400	100	400	1.1	1.5	1420	295*250	4*5
CELL-150-400	150				2130	295*250	4*5
CELL-200-400	200				2840	295*250	4*5
CELL-100-445	100	445	1.1	1.5	1420	320*287	2.56*8.35
CELL-150-445	150				2130	320*287	2.56*8.35
CELL-200-445	200				2840	320*287	2.56*8.35
CELL-100-660	100	660	1.1	1.5	1420	488*406	2.44*12.29
CELL-150-660	150				2130	488*406	2.44*12.29
CELL-200-660	200				2840	488*406	2.44*12.29
CELL-100-712	100	712	1.1	1.5	1420	508*475	2.56*13.72
CELL-150-712	150				2130	508*475	2.56*13.72
CELL-200-712	200				2840	508*475	2.56*13.72

Key Features & Benefits

1. Superior Load Distribution & Reinforcement

Cellular Geocell unique honeycomb structure effectively distributes vertical and lateral loads, preventing soil displacement and subsidence. This makes it ideal for roadways, parking lots, and heavy-traffic areas where traditional methods may fail.

2. Enhanced Soil Stabilization

By confining gravel, sand, or soil within its cells, Cellular Geocell prevents particle migration and increases shear strength. This results in a stable, reinforced base that resists deformation under stress.

3. Cost-Effective & Sustainable Solution

Compared to conventional methods like deep excavation or concrete reinforcement, Cellular Geocell reduces material usage and construction time. It allows for the use of locally available infill, cutting costs while maintaining structural integrity.

4. Erosion Control & Slope Protection

On slopes, embankments, and channels, Cellular Geocell prevents soil erosion caused by water flow and wind. Its interconnected cells anchor vegetation, promoting natural reinforcement while maintaining landscape aesthetics.

5. Easy Installation & Versatility

Lightweight and flexible, Cellular Geocell can be quickly deployed in various terrains-flat surfaces, steep slopes, or uneven ground. It adapts to different infill materials, making it suitable for multiple applications.

5. Easy Installation & Versatility

Manufactured from high-density polyethylene (HDPE) or other UV-stabilized polymers, Cellular Geocell resists chemical degradation, extreme temperatures, and mechanical wear, ensuring a long service life.

Applications of Cellular Geocell

1. Road & Pavement Construction

Base Reinforcement: Strengthens weak subgrades for highways, rural roads, and temporary access roads.

Pavement Support: Reduces rutting and cracking in asphalt or unpaved surfaces.

Shoulder Stabilization: Prevents edge deterioration on road shoulders.

2. Slope & Embankment Protection

Erosion Control: Secures soil on steep slopes against water and wind erosion.

Vegetative Support: Holds topsoil and promotes root growth for reinforced green slopes.

3. Retaining Walls & Earth Retention

Gravity Walls: Provides structural stability for reinforced earth walls.

Channel Linings: Protects against scour in drainage systems and riverbanks.

4. Military & Emergency Access

Rapid Deployment: Creates stable surfaces for temporary roads in disaster zones or military operations.

Helipads & Landing Zones: Reinforces soft ground for aircraft and heavy machinery.

5. Landscaping & Recreational Areas

Parking Lots & Driveways: Enhances load-bearing capacity for residential and commercial areas.

Green Roofs & Garden Stabilization: Supports soil in landscaped environments.

product-800-692

FAQ

Q: What is Cellular Geocell?
A: Cellular Geocell is a 3D honeycomb-like structure made from high-strength polymers, used to confine and stabilize soil, gravel, or other infill materials for ground reinforcement.

Q: How does Cellular Geocell work?
A: The interconnected cells confine infill materials, creating a stiffened composite layer that distributes loads evenly and prevents lateral movement of particles.

Q: What makes Cellular Geocell different from traditional geogrids?
A: Unlike flat geogrids, Cellular Geocell provides 3D confinement that offers vertical support and prevents infill material migration in all directions.

Q: Can Cellular Geocell be used in waterlogged areas?
A: Yes, its permeable design allows water drainage while maintaining structural integrity, making it ideal for wetlands and flood-prone zones.
